Premium LuAG(Ce) Scintillators & High-Res Imaging Screens
Cerium-doped Lutetium Aluminum Garnet (LuAG:Ce) is an established, high-density scintillator renowned for its robust chemical, mechanical, and temperature resistance. It is the premier choice for advanced medical scanning systems and high-energy particle detectors.
- Fast & Efficient: Delivers a rapid 70ns decay time and exceptional light yield alongside a high density of 6.73g/cm³.
- Optimal Readout: Peak emission at 535nm, perfectly matched for seamless photodiode and avalanche diode integration.
- Custom Configurations: Supplying precision-machined standalone LuAG(Ce) crystals and customized ultra-thin imaging screens.
ATR Crystal LuAG(Ce) Scintillators
Description
Parameter
Description
Application of LuAG(Ce) Scintillators (LuAG:Ce Scintillators)
PET Scanners
High Energy Physics
X-ray imaging screens
X-ray microscopy
X-ray computed tomography (XCT)
Advantages of LuAG(Ce) Scintillators (LuAG:Ce Scintillators)
Fast decay time
High density
Excellent physical and chemical properties
The wavelength of peak emission well suitable for photodiode and avalanche diode readout
Good temperature resistance
The Ability of ATR Crystal
Maximum Size: ɸ80mm x 150mm
Available items: monolithic crystal, scintillation screen
Scintillation Screen Design Options of LuAG(Ce) Scintillators (LuAG:Ce Scintillators)
Freestanding ultra-thin scintillation screen.
Ultra-thin scintillation screens can be coupled to a substrate with optical adhesives in order to achieve better optical readout.
Scintillation screens can be inserted into frames(Aluminum, Stainless steel) for easier manipulation.
We can provide customized marking such as a grid, cross or scale on the surface of the screen for easier beam visualization.
We can provide various coating on the surface of the screen upon request, such as reflection coatings(Al, Au, Ag, etc.), AR coating, diffusion painting(TiO2, Al2O3), and conductive coatings(Al, ITO, C).
Parameter
Properties of LuAG(Ce) Scintillators (LuAG:Ce Scintillators)
| Density (g/cm3) | 6.73 |
|---|---|
| Hardness (Mohs) | 8.5 |
| Index of Refraction | 1.84 |
| Melting Point (°C) | 2020 |
| Crystal Structure | Cubic |
| Hygroscopic | None |
| Wavelength of Max. Emission (nm) | 535 |
| Decay Time (ns) | 70 |
| Radiation Length for 511 keV (cm) | 1.3 |
| Photon Yield (Photons/MeV) | 25000 |
| Light Yield (Relative NaI(Tl)=100%) | 20 |
